UCD7201PWP Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
- Description: IC GATE DRVR LOW-SIDE 14HTSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCD7201PWP Specifications:
- MfrPart.: UCD7201PWP
- Mfr: Texas Instruments
- Description: IC GATE DRVR LOW-SIDE 14HTSSOP
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- DrivenConfiguration: Low-Side
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: N-Channel MOSFET
- Voltage-Supply: 4.25V ~ 15V
- LogicVoltage-VILVIH: 1.16V, 2.08V
- Current-PeakOutput(SourceSink): 4A, 4A
- InputType: Non-Inverting
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 10ns, 10ns
- OperatingTemperature: -40°C ~ 105°C (TJ)
- MountingType: Surface Mount
- Package/Case: 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
- UCD7201PWP TI, IC GATE DRVR LOW-SIDE 14HTSSOP, Integrated Circuits (ICs)~PMIC - Gate Drivers
UCD7201PWP, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
