UCC3804NG4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 8-DIP (0.300, 7.62mm)
- Description: IC OFFLINE SWITCH MULT TOP 8DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC3804NG4 Specifications:
- MfrPart.: UCC3804NG4
- Mfr: Texas Instruments
- Description: IC OFFLINE SWITCH MULT TOP 8DIP
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tube
- Series: -
- PartStatus: Active
- OutputIsolation: -
- InternalSwitch(s): No
- Voltage-Breakdown: -
- Topology: Boost, Buck, Flyback, Forward
- Voltage-StartUp: 12.5 V
- Voltage-Supply(Vcc/Vdd): 8.3V ~ 12V
- DutyCycle: 49%
- Frequency-Switching: Up to 1MHz
- Power(Watts): -
- FaultProtection: Current Limiting
- ControlFeatures: Frequency Control
- OperatingTemperature: -40°C ~ 85°C (TA)
- Package/Case: 8-DIP (0.300, 7.62mm)
- UCC3804NG4 TI, IC OFFLINE SWITCH MULT TOP 8DIP, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
UCC3804NG4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
