UCC3580N-2G4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC OFFLINE SWITCH MULT TOP 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC3580N-2G4 Specifications:
- MfrPart.: UCC3580N-2G4
- Mfr: Texas Instruments
- Description: IC OFFLINE SWITCH MULT TOP 16DIP
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- OutputIsolation: Isolated
- InternalSwitch(s): No
- Voltage-Breakdown: -
- Topology: Flyback, Forward
- Voltage-StartUp: 15 V
- Voltage-Supply(Vcc/Vdd): 8.5V ~ 15V
- DutyCycle: 66%
- Frequency-Switching: -
- Power(Watts): -
- FaultProtection: -
- ControlFeatures: Soft Start
- OperatingTemperature: -55°C ~ 150°C (TJ)
- Package/Case: 16-DIP (0.300, 7.62mm)
- UCC3580N-2G4 TI, IC OFFLINE SWITCH MULT TOP 16DIP, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
UCC3580N-2G4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
