UCC2806DWTR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: IC REG CTRLR MULT TOP 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC2806DWTR Specifications:
- MfrPart.: UCC2806DWTR
- Mfr: Texas Instruments
- Description: IC REG CTRLR MULT TOP 16SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- OutputConfiguration: Positive, Isolation Capable
- Topology: Boost, Flyback, Forward Converter
- NumberofOutputs: 2
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 8V ~ 14.5V
- Frequency-Switching: 47kHz
- DutyCycle(Max): 50%
- SynchronousRectifier: Yes
- ClockSync: No
- SerialInterfaces: -
- ControlFeatures: Current Limit, Enable, Frequency Control
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- UCC2806DWTR TI, IC REG CTRLR MULT TOP 16SOIC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
UCC2806DWTR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
