UCC21736QDWQ1 Images
- Manufacturer: Texas Instruments (TI)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: AUTOMOTIVE 10-A ISOLATED SINGLE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC21736QDWQ1 Specifications:
- MfrPart.: UCC21736QDWQ1
- Mfr: Texas Instruments
- Description: AUTOMOTIVE 10-A ISOLATED SINGLE
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tube
- Series: Automotive, AEC-Q100
- PartStatus: Active
- Technology: Capacitive Coupling
- NumberofChannels: 1
- Voltage-Isolation: 5700Vrms
- CommonModeTransientImmunity(Min): 150V/ns
- PropagationDelaytpLH/tpHL(Max): 90ns, 90ns
- PulseWidthDistortion(Max): 25ns
- Rise/FallTime(Typ): 28ns, 24ns (Max)
- Current-OutputHighLow: 10A, 10A
- Current-PeakOutput: 10A
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 13V ~ 33V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- UCC21736QDWQ1 TI, AUTOMOTIVE 10-A ISOLATED SINGLE, Isolators~Isolators - Gate Drivers
UCC21736QDWQ1, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
