UCC21530QDWKRQ1 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 14-SOIC (0.295, 7.50mm Width)
- Description: IC GATE DRVR ISOLATED
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC21530QDWKRQ1 Specifications:
- MfrPart.: UCC21530QDWKRQ1
- Mfr: Texas Instruments
- Description: IC GATE DRVR ISOLATED
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q100
- PartStatus: Obsolete
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: IGBT, N-Channel, P-Channel MOSFET
- Voltage-Supply: 3V ~ 18V
- LogicVoltage-VILVIH: 1.2V, 1.6V
- Current-PeakOutput(SourceSink): 4A, 6A
- InputType: CMOS/TTL
- HighSideVoltage-Max(Bootstrap): -
- Rise/FallTime(Typ): 6ns, 7ns
- OperatingTemperature: -40°C ~ 130°C (TJ)
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.295, 7.50mm Width)
- UCC21530QDWKRQ1 TI, IC GATE DRVR ISOLATED, Integrated Circuits (ICs)~PMIC - Gate Drivers
