UCC21220ADR Images
- Manufacturer: Texas Instruments (TI)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: PWR MGMT MOSFET/PWR DRIVER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UCC21220ADR Specifications:
- MfrPart.: UCC21220ADR
- Mfr: Texas Instruments
- Description: PWR MGMT MOSFET/PWR DRIVER
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- Technology: Capacitive Coupling
- NumberofChannels: 2
- Voltage-Isolation: 3000Vrms
- CommonModeTransientImmunity(Min): 100V/ns
- PropagationDelaytpLH/tpHL(Max): 40ns, 40ns
- PulseWidthDistortion(Max): 5.5ns
- Rise/FallTime(Typ): 5ns, 6ns
- Current-OutputHighLow: 4A, 6A
- Current-PeakOutput: 4A, 6A
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 6V ~ 18V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- UCC21220ADR TI, PWR MGMT MOSFET/PWR DRIVER, Isolators~Isolators - Gate Drivers
UCC21220ADR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
