UC2823BNG4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC OFFLINE SWITCH MULT TOP 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
UC2823BNG4 Specifications:
- MfrPart.: UC2823BNG4
- Mfr: Texas Instruments
- Description: IC OFFLINE SWITCH MULT TOP 16DIP
- Product Category: Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- OutputIsolation: Non-Isolated
- InternalSwitch(s): No
- Voltage-Breakdown: -
- Topology: Boost, Buck, Flyback, Forward
- Voltage-StartUp: 16 V
- Voltage-Supply(Vcc/Vdd): 10V ~ 22V
- DutyCycle: 100%
- Frequency-Switching: 1MHz
- Power(Watts): -
- FaultProtection: Current Limiting
- ControlFeatures: Frequency Control, Soft Start
- OperatingTemperature: -55°C ~ 150°C (TJ)
- Package/Case: 16-DIP (0.300, 7.62mm)
- UC2823BNG4 TI, IC OFFLINE SWITCH MULT TOP 16DIP, Integrated Circuits (ICs)~PMIC - AC DC Converters, Offline Switchers
UC2823BNG4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
