TS3A5017D Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC SWITCH DUAL SP4T 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TS3A5017D Specifications:
- MfrPart.: TS3A5017D
- Mfr: Texas Instruments
- Description: IC SWITCH DUAL SP4T 16SOIC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 12Ohm
- Channel-to-ChannelMatching(ΔRon): 1Ohm
- Voltage-SupplySingle(V+): 2.3V ~ 3.6V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 9.5ns, 3.5ns
- -3dbBandwidth: 165MHz
- ChargeInjection: 5pC
- ChannelCapacitance(CS(off)CD(off)): 4.5pF, 19pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -49dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- TS3A5017D TI, IC SWITCH DUAL SP4T 16SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
TS3A5017D, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
