TPS72501DCQR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: SOT-223-6
- Description: IC REG LIN POS ADJ 1A SOT223-6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TPS72501DCQR Specifications:
- MfrPart.: TPS72501DCQR
- Mfr: Texas Instruments
- Description: IC REG LIN POS ADJ 1A SOT223-6
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputConfiguration: Positive
- OutputType: Adjustable
- NumberofRegulators: 1
- Voltage-Input(Max): 6V
- Voltage-Output(Min/Fixed): 1.22V
- Voltage-Output(Max): 5.5V
- VoltageDropout(Max): 0.28V @ 1A
- Current-Output: 1A
- Current-Quiescent(Iq): 225 µA
- Current-Supply(Max): 325 µA
- PSRR: 60dB (1kHz)
- ControlFeatures: Enable, Reset
- ProtectionFeatures: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: SOT-223-6
- TPS72501DCQR TI, IC REG LIN POS ADJ 1A SOT223-6, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
TPS72501DCQR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
