TPS72301DBVT Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: SC-74A, SOT-753
- Description: IC REG LIN NEG ADJ 200MA SOT23-5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TPS72301DBVT Specifications:
- MfrPart.: TPS72301DBVT
- Mfr: Texas Instruments
- Description: IC REG LIN NEG ADJ 200MA SOT23-5
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputConfiguration: Negative
- OutputType: Adjustable
- NumberofRegulators: 1
- Voltage-Input(Max): -10V
- Voltage-Output(Min/Fixed): -1.2V
- Voltage-Output(Max): -10V
- VoltageDropout(Max): 0.5V @ 200mA
- Current-Output: 200mA
- Current-Quiescent(Iq): 200 µA
- Current-Supply(Max): 500 µA
- PSRR: 65dB ~ 48dB (1kHz ~ 10kHz)
- ControlFeatures: Enable
- ProtectionFeatures: Over Current, Over Temperature, Short Circuit
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: SC-74A, SOT-753
- TPS72301DBVT TI, IC REG LIN NEG ADJ 200MA SOT23-5, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
TPS72301DBVT, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
