TPS2814DG4 TI IC GATE DRVR LOW-SIDE 8SOIC
TPS2814DG4 Images
TPS2814DG4 Images
TPS2814DG4
  • Manufacturer: Texas Instruments (TI)
  • Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • Description: IC GATE DRVR LOW-SIDE 8SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
TPS2814DG4 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
TPS2814DG4 Specifications:
  • MfrPart.: TPS2814DG4
  • Mfr: Texas Instruments
  • Description: IC GATE DRVR LOW-SIDE 8SOIC
  • Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • DrivenConfiguration: Low-Side
  • ChannelType: Synchronous
  • NumberofDrivers: 2
  • GateType: N-Channel, P-Channel MOSFET
  • Voltage-Supply: 4V ~ 14V
  • LogicVoltage-VILVIH: 1V, 4V
  • Current-PeakOutput(SourceSink): 2A, 2A
  • InputType: Inverting, Non-Inverting
  • HighSideVoltage-Max(Bootstrap): -
  • Rise/FallTime(Typ): 14ns, 15ns
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 8-SOIC (0.154, 3.90mm Width)
  • TPS2814DG4 TI, IC GATE DRVR LOW-SIDE 8SOIC, Integrated Circuits (ICs)~PMIC - Gate Drivers
