TPS1101D Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
- Description: MOSFET P-CH 15V 2.3A 8SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TPS1101D Specifications:
- MfrPart.: TPS1101D
- Mfr: Texas Instruments
- Description: MOSFET P-CH 15V 2.3A 8SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 15 V
- Current-ContinuousDrain(Id)@25°C: 2.3A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.7V, 10V
- RdsOn(Max)@IdVgs: 90mOhm @ 2.5A, 10V
- Vgs(th)(Max)@Id: 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 11.25 nC @ 10 V
- Vgs(Max): +2V, -15V
- InputCapacitance(Ciss)(Max)@Vds: -
- FETFeature: -
- PowerDissipation(Max): 791mW (Ta)
- OperatingTemperature: -40°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: 8-SOIC
- TPS1101D TI, MOSFET P-CH 15V 2.3A 8SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
TPS1101D, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
