TMUX6212PWR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: 36-V LOW RON, 1:1, 4 CHANNEL, MU
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TMUX6212PWR Specifications:
- MfrPart.: TMUX6212PWR
- Mfr: Texas Instruments
- Description: 36-V LOW RON, 1:1, 4 CHANNEL, MU
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 3.1Ohm
- Channel-to-ChannelMatching(ΔRon): 100mOhm
- Voltage-SupplySingle(V+): 4.5V ~ 36V, ±4.5V ~ 16V
- Voltage-SupplyDual(V±): 4.5V ~ 36V, ±4.5V ~ 16V
- SwitchTime(TonToff)(Max): 180ns, 220ns
- -3dbBandwidth: 50MHz
- ChargeInjection: 78pC
- ChannelCapacitance(CS(off)CD(off)): 28pF, 45pF
- Current-Leakage(IS(off))(Max): 50pA
- Crosstalk: -93dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- TMUX6212PWR TI, 36-V LOW RON, 1:1, 4 CHANNEL, MU, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
TMUX6212PWR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
