TMUX1309BQBR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-WFQFN Exposed Pad
- Description: 2-CHANNEL, 4:1 GENERAL-PURPOSE A
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TMUX1309BQBR Specifications:
- MfrPart.: TMUX1309BQBR
- Mfr: Texas Instruments
- Description: 2-CHANNEL, 4:1 GENERAL-PURPOSE A
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 195Ohm
- Channel-to-ChannelMatching(ΔRon): 7Ohm
- Voltage-SupplySingle(V+): 1.62V ~ 5.5V
- Voltage-SupplyDual(V±): 1.62V ~ 5.5V
- SwitchTime(TonToff)(Max): 32ns, 40ns
- -3dbBandwidth: 500MHz
- ChargeInjection: -6.5pC
- ChannelCapacitance(CS(off)CD(off)): 14pF, 7pF
- Current-Leakage(IS(off))(Max): 1pA (Typ)
- Crosstalk: -90dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-WFQFN Exposed Pad
- TMUX1309BQBR TI, 2-CHANNEL, 4:1 GENERAL-PURPOSE A, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
TMUX1309BQBR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
