TMUX1204DQAR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 10-UFDFN
- Description: IC SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TMUX1204DQAR Specifications:
- MfrPart.: TMUX1204DQAR
- Mfr: Texas Instruments
- Description: IC SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 1
- On-StateResistance(Max): 5Ohm (Typ)
- Channel-to-ChannelMatching(ΔRon): 150mOhm
- Voltage-SupplySingle(V+): 1.08V ~ 5.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 14ns, 5ns (Typ)
- -3dbBandwidth: 125MHz
- ChargeInjection: 9pC
- ChannelCapacitance(CS(off)CD(off)): 13pF, 38pF
- Current-Leakage(IS(off))(Max): 75nA (Typ)
- Crosstalk: -42dB @ 10MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: -
- Package/Case: 10-UFDFN
- TMUX1204DQAR TI, IC SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
TMUX1204DQAR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
