TL431QDBZR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Reference Package/Case: TO-236-3, SC-59, SOT-23-3
- Description: IC VREF SHUNT ADJ 2.2% SOT23-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TL431QDBZR Specifications:
- MfrPart.: TL431QDBZR
- Mfr: Texas Instruments
- Description: IC VREF SHUNT ADJ 2.2% SOT23-3
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Reference
- Package: Bulk
- Series: -
- PartStatus: Active
- ReferenceType: Shunt
- OutputType: Adjustable
- Voltage-Output(Min/Fixed): 2.495V
- Voltage-Output(Max): 36 V
- Current-Output: 100 mA
- Tolerance: ±2.2%
- TemperatureCoefficient: -
- Noise-01Hzto10Hz: -
- Noise-10Hzto10kHz: -
- Voltage-Input: -
- Current-Supply: -
- Current-Cathode: 1 mA
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: TO-236-3, SC-59, SOT-23-3
- TL431QDBZR TI, IC VREF SHUNT ADJ 2.2% SOT23-3, Integrated Circuits (ICs)~PMIC - Voltage Reference
TL431QDBZR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
