SN74S51DR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters - Multi-Function, Configurable Package/Case: 14-SOIC (0.154, 3.90mm Width)
- Description: IC DUA AND-OR-INVERT GATE 14SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74S51DR Specifications:
- MfrPart.: SN74S51DR
- Mfr: Texas Instruments
- Description: IC DUA AND-OR-INVERT GATE 14SOIC
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters - Multi-Function, Configurable
- Package: Tape & Reel (TR)
- Series: 74S
- PartStatus: Obsolete
- LogicType: AND/OR/INVERT Gate
- NumberofCircuits: 2
- NumberofInputs: 8 Input (2, 2, 2, 2)
- SchmittTriggerInput: No
- OutputType: Single-Ended
- Current-OutputHighLow: 1mA, 20mA
- Voltage-Supply: 4.75V ~ 5.25V
- OperatingTemperature: 0°C ~ 70°C
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.154, 3.90mm Width)
- SN74S51DR TI, IC DUA AND-OR-INVERT GATE 14SOIC, Integrated Circuits (ICs)~Logic - Gates and Inverters - Multi-Function, Configurable
SN74S51DR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
