SN74LVC86APWT Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-TSSOP
- Description: IC GATE XOR 4CH 2-INP 14TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74LVC86APWT Specifications:
- MfrPart.: SN74LVC86APWT
- Mfr: Texas Instruments
- Description: IC GATE XOR 4CH 2-INP 14TSSOP
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR)
- Series: 74LVC
- PartStatus: Discontinued at
- LogicType: XOR (Exclusive OR)
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 1.65V ~ 3.6V
- Current-Quiescent(Max): 1 µA
- Current-OutputHighLow: 24mA, 24mA
- LogicLevel-Low: 0.7V ~ 0.8V
- LogicLevel-High: 1.7V ~ 2V
- MaxPropagationDelay@VMaxCL: 4.4ns @ 3.3V, 50pF
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- SupplierDevicePackage: 14-TSSOP
- SN74LVC86APWT TI, IC GATE XOR 4CH 2-INP 14TSSOP, Integrated Circuits (ICs)~Logic - Gates and Inverters
SN74LVC86APWT, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
