SN74LVC1G3157DCKR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 6-TSSOP, SC-88, SOT-363
- Description: IC SWITCH SPDT SC70-6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74LVC1G3157DCKR Specifications:
- MfrPart.: SN74LVC1G3157DCKR
- Mfr: Texas Instruments
- Description: IC SWITCH SPDT SC70-6
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 1
- On-StateResistance(Max): 15Ohm
- Channel-to-ChannelMatching(ΔRon): 100mOhm
- Voltage-SupplySingle(V+): 1.65V ~ 5.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 5.7ns, 3.8ns
- -3dbBandwidth: 340MHz
- ChargeInjection: 7pC
- ChannelCapacitance(CS(off)CD(off)): 5.2pF
- Current-Leakage(IS(off))(Max): 1µA
- Crosstalk: -54dB @ 10MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 6-TSSOP, SC-88, SOT-363
- SN74LVC1G3157DCKR TI, IC SWITCH SPDT SC70-6, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
SN74LVC1G3157DCKR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
