SN74LVC1G00DBVRG4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: SOT-23-5
- Description: IC GATE NAND 1CH 2-INP SOT23-5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74LVC1G00DBVRG4 Specifications:
- MfrPart.: SN74LVC1G00DBVRG4
- Mfr: Texas Instruments
- Description: IC GATE NAND 1CH 2-INP SOT23-5
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: 74LVC
- PartStatus: Active
- LogicType: NAND Gate
- NumberofCircuits: 1
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 1.65V ~ 5.5V
- Current-Quiescent(Max): 10 µA
- Current-OutputHighLow: 32mA, 32mA
- LogicLevel-Low: 0.7V ~ 0.8V
- LogicLevel-High: 1.7V ~ 2V
- MaxPropagationDelay@VMaxCL: 4.3ns @ 5V, 50pF
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-5
- SN74LVC1G00DBVRG4 TI, IC GATE NAND 1CH 2-INP SOT23-5, Integrated Circuits (ICs)~Logic - Gates and Inverters
SN74LVC1G00DBVRG4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
