SN74LV4052ADBR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SSOP (0.209, 5.30mm Width)
- Description: IC MULTIPLEXER DUAL 4X1 16SSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74LV4052ADBR Specifications:
- MfrPart.: SN74LV4052ADBR
- Mfr: Texas Instruments
- Description: IC MULTIPLEXER DUAL 4X1 16SSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 75Ohm
- Channel-to-ChannelMatching(ΔRon): 700mOhm
- Voltage-SupplySingle(V+): 2V ~ 5.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 14ns, 14ns
- -3dbBandwidth: 50MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 0.5pF, 13.1pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -45dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SSOP (0.209, 5.30mm Width)
- SN74LV4052ADBR TI, IC MULTIPLEXER DUAL 4X1 16SSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
SN74LV4052ADBR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
