SN74LV1T86DCKRG4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: SC-70-5
- Description: IC GATE XOR 1CH 2-INP SC70-5
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74LV1T86DCKRG4 Specifications:
- MfrPart.: SN74LV1T86DCKRG4
- Mfr: Texas Instruments
- Description: IC GATE XOR 1CH 2-INP SC70-5
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: 74LV
- PartStatus: Active
- LogicType: XOR (Exclusive OR)
- NumberofCircuits: 1
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 1.6V ~ 5.5V
- Current-Quiescent(Max): 10 µA
- Current-OutputHighLow: 8mA, 8mA
- LogicLevel-Low: 0.58V ~ 0.8V
- LogicLevel-High: 0.94V ~ 2.1V
- MaxPropagationDelay@VMaxCL: 7ns @ 5V, 30pF
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- SupplierDevicePackage: SC-70-5
- SN74LV1T86DCKRG4 TI, IC GATE XOR 1CH 2-INP SC70-5, Integrated Circuits (ICs)~Logic - Gates and Inverters
