SN74HC7002PWT Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-TSSOP
- Description: IC GATE NOR 4CH 2-INP 14TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74HC7002PWT Specifications:
- MfrPart.: SN74HC7002PWT
- Mfr: Texas Instruments
- Description: IC GATE NOR 4CH 2-INP 14TSSOP
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR)
- Series: 74HC
- PartStatus: Discontinued at
- LogicType: NOR Gate
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: Schmitt Trigger
- Voltage-Supply: 2V ~ 6V
- Current-Quiescent(Max): 2 µA
- Current-OutputHighLow: 5.2mA, 5.2mA
- LogicLevel-Low: 0.3V ~ 1.2V
- LogicLevel-High: 1.5V ~ 4.2V
- MaxPropagationDelay@VMaxCL: 22ns @ 6V, 50pF
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- SupplierDevicePackage: 14-TSSOP
- SN74HC7002PWT TI, IC GATE NOR 4CH 2-INP 14TSSOP, Integrated Circuits (ICs)~Logic - Gates and Inverters
SN74HC7002PWT, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
