SN74HC4066DRG4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 14-SOIC (0.154, 3.90mm Width)
- Description: IC SWITCH QUAD 1X1 14SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74HC4066DRG4 Specifications:
- MfrPart.: SN74HC4066DRG4
- Mfr: Texas Instruments
- Description: IC SWITCH QUAD 1X1 14SOIC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 30Ohm (Typ)
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): 2V ~ 6V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 31ns, 34ns
- -3dbBandwidth: 30MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 0.5pF, 9pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -45dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.154, 3.90mm Width)
- SN74HC4066DRG4 TI, IC SWITCH QUAD 1X1 14SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
SN74HC4066DRG4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
