SN74HC132ANSR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-SO
- Description: IC GATE NAND SCHMIT 4CH 2IN 14SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74HC132ANSR Specifications:
- MfrPart.: SN74HC132ANSR
- Mfr: Texas Instruments
- Description: IC GATE NAND SCHMIT 4CH 2IN 14SO
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: 74HC
- PartStatus: Obsolete
- LogicType: NAND Gate
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: Schmitt Trigger
- Voltage-Supply: 2V ~ 6V
- Current-Quiescent(Max): 2 µA
- Current-OutputHighLow: 5.2mA, 5.2mA
- LogicLevel-Low: 0.1V ~ 0.26V
- LogicLevel-High: 1.9V ~ 5.9V
- MaxPropagationDelay@VMaxCL: 19ns @ 6V, 50pF
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- SupplierDevicePackage: 14-SO
- SN74HC132ANSR TI, IC GATE NAND SCHMIT 4CH 2IN 14SO, Integrated Circuits (ICs)~Logic - Gates and Inverters
SN74HC132ANSR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
