SN74AS02N TI IC GATE NOR 4CH 2-INP 14DIP
SN74AS02N Images
SN74AS02N Images
SN74AS02N
  • Manufacturer: Texas Instruments (TI)
  • Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-PDIP
  • Description: IC GATE NOR 4CH 2-INP 14DIP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SN74AS02N Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SN74AS02N Specifications:
  • MfrPart.: SN74AS02N
  • Mfr: Texas Instruments
  • Description: IC GATE NOR 4CH 2-INP 14DIP
  • Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
  • Package: Tube
  • Series: 74AS
  • PartStatus: Active
  • LogicType: NOR Gate
  • NumberofCircuits: 4
  • NumberofInputs: 2
  • Features: -
  • Voltage-Supply: 4.5V ~ 5.5V
  • Current-Quiescent(Max): -
  • Current-OutputHighLow: 2mA, 20mA
  • LogicLevel-Low: 0.8V
  • LogicLevel-High: 2V
  • MaxPropagationDelay@VMaxCL: 4.5ns @ 5V, 50pF
  • OperatingTemperature: 0°C ~ 70°C
  • MountingType: Through Hole
  • SupplierDevicePackage: 14-PDIP
  • SN74AS02N TI, IC GATE NOR 4CH 2-INP 14DIP, Integrated Circuits (ICs)~Logic - Gates and Inverters
