SN74ALVC00NSR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-SO
- Description: IC GATE NAND 4CH 2-INP 14SOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SN74ALVC00NSR Specifications:
- MfrPart.: SN74ALVC00NSR
- Mfr: Texas Instruments
- Description: IC GATE NAND 4CH 2-INP 14SOP
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: 74ALVC
- PartStatus: Active
- LogicType: NAND Gate
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 1.65V ~ 3.6V
- Current-Quiescent(Max): 10 µA
- Current-OutputHighLow: 24mA, 24mA
- LogicLevel-Low: 0.7V ~ 0.8V
- LogicLevel-High: 1.7V ~ 2V
- MaxPropagationDelay@VMaxCL: 3ns @ 3.3V, 50pF
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- SupplierDevicePackage: 14-SO
- SN74ALVC00NSR TI, IC GATE NAND 4CH 2-INP 14SOP, Integrated Circuits (ICs)~Logic - Gates and Inverters
SN74ALVC00NSR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
