PTN78000HAZ Images
- Manufacturer: Texas Instruments (TI)
- Category: Power Supplies - Board Mount~DC DC Converters Package/Case: 5-SMD Module
- Description: DC DC CONVERTER 11.85-22V
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PTN78000HAZ Specifications:
- MfrPart.: PTN78000HAZ
- Mfr: Texas Instruments
- Description: DC DC CONVERTER 11.85-22V
- Product Category: Power Supplies - Board Mount~DC DC Converters
- Package: Tray
- Series: PTN78000H
- PartStatus: Active
- Type: Non-Isolated PoL Module
- NumberofOutputs: 1
- Voltage-Input(Min): 15V
- Voltage-Input(Max): 36V
- Voltage-Output1: 11.85 ~ 22V
- Voltage-Output2: -
- Voltage-Output3: -
- Voltage-Output4: -
- Current-Output(Max): 1.5A
- Power(Watts): -
- Voltage-Isolation: -
- Applications: ITE (Commercial)
- Features: OCP, OTP, UVLO
- OperatingTemperature: -40°C ~ 85°C
- Efficiency: 94%
- MountingType: Surface Mount
- Package/Case: 5-SMD Module
- Size/Dimension: 0.75 L x 0.50 W x 0.36 H (19.1mm x 12.7mm x 9.1mm)
- SupplierDevicePackage: -
- ControlFeatures: -
- ApprovalAgency: -
- PTN78000HAZ TI, DC DC CONVERTER 11.85-22V, Power Supplies - Board Mount~DC DC Converters
PTN78000HAZ, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
