PTB78560AAH Images
- Manufacturer: Texas Instruments (TI)
- Category: Power Supplies - Board Mount~DC DC Converters Package/Case: 11-DIP Module
- Description: DC DC CONVERTER 3.6-5.5V 30W
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PTB78560AAH Specifications:
- MfrPart.: PTB78560AAH
- Mfr: Texas Instruments
- Description: DC DC CONVERTER 3.6-5.5V 30W
- Product Category: Power Supplies - Board Mount~DC DC Converters
- Package: Tray
- Series: PTB78560 (30W)
- PartStatus: Not For New Designs
- Type: Isolated Module
- NumberofOutputs: 1
- Voltage-Input(Min): 18V
- Voltage-Input(Max): 60V
- Voltage-Output1: 3.6 ~ 5.5V
- Voltage-Output2: -
- Voltage-Output3: -
- Voltage-Output4: -
- Current-Output(Max): 6A
- Power(Watts): 30 W
- Voltage-Isolation: 1.5 kV
- Applications: ITE (Commercial)
- Features: -
- OperatingTemperature: -40°C ~ 85°C
- Efficiency: 83%
- MountingType: Through Hole
- Package/Case: 11-DIP Module
- Size/Dimension: 2.05 L x 1.05 W x 0.39 H (52.1mm x 26.7mm x 10.0mm)
- SupplierDevicePackage: -
- ControlFeatures: -
- ApprovalAgency: -
- PTB78560AAH TI, DC DC CONVERTER 3.6-5.5V 30W, Power Supplies - Board Mount~DC DC Converters
PTB78560AAH, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
