PT6506B Images
- Manufacturer: Texas Instruments (TI)
- Category: Power Supplies - Board Mount~DC DC Converters Package/Case: 14-SMD Module
- Description: SWITCHING REGLTR, VOLTAGE-MODE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
PT6506B Specifications:
- MfrPart.: PT6506B
- Mfr: Texas Instruments
- Description: SWITCHING REGLTR, VOLTAGE-MODE
- Product Category: Power Supplies - Board Mount~DC DC Converters
- Package: Tray
- Series: PT6500
- PartStatus: Obsolete
- Type: Non-Isolated PoL Module
- NumberofOutputs: 1
- Voltage-Input(Min): 3.1V
- Voltage-Input(Max): 6V
- Voltage-Output1: 1.8V
- Voltage-Output2: -
- Voltage-Output3: -
- Voltage-Output4: -
- Current-Output(Max): 8A
- Power(Watts): -
- Voltage-Isolation: -
- Applications: ITE (Commercial)
- Features: OTP, SCP
- OperatingTemperature: -40°C ~ 85°C
- Efficiency: 74%
- MountingType: Surface Mount
- Package/Case: 14-SMD Module
- Size/Dimension: 2.36 L x 1.22 W x 0.42 H (59.9mm x 31.0mm x 10.7mm)
- SupplierDevicePackage: -
- ControlFeatures: -
- ApprovalAgency: -
- PT6506B TI, SWITCHING REGLTR, VOLTAGE-MODE, Power Supplies - Board Mount~DC DC Converters
