MUX509IPW Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: IC MUX DUAL 4:1 170 OHM 16TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MUX509IPW Specifications:
- MfrPart.: MUX509IPW
- Mfr: Texas Instruments
- Description: IC MUX DUAL 4:1 170 OHM 16TSSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 170Ohm
- Channel-to-ChannelMatching(ΔRon): 2.4Ohm
- Voltage-SupplySingle(V+): 10V ~ 36V
- Voltage-SupplyDual(V±): ±5V ~ 18V
- SwitchTime(TonToff)(Max): 136ns, 75ns
- -3dbBandwidth: -
- ChargeInjection: 0.3pC
- ChannelCapacitance(CS(off)CD(off)): 2.4pF, 4.3pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -96dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- MUX509IPW TI, IC MUX DUAL 4:1 170 OHM 16TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MUX509IPW, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
