MUX506IDWR TI IC SWITCH SINGLE 28SOIC
MUX506IDWR Images
MUX506IDWR Images
  • Manufacturer: Texas Instruments (TI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 28-SOIC (0.295, 7.50mm Width)
  • Description: IC SWITCH SINGLE 28SOIC
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
MUX506IDWR Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
MUX506IDWR Specifications:
  • MfrPart.: MUX506IDWR
  • Mfr: Texas Instruments
  • Description: IC SWITCH SINGLE 28SOIC
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Active
  • SwitchCircuit: -
  • Multiplexer/DemultiplexerCircuit: 16:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 200Ohm
  • Channel-to-ChannelMatching(ΔRon): 6Ohm
  • Voltage-SupplySingle(V+): 10V ~ 36V
  • Voltage-SupplyDual(V±): ±5V ~ 18V
  • SwitchTime(TonToff)(Max): 136ns, 78ns
  • -3dbBandwidth: -
  • ChargeInjection: 0.67pC
  • ChannelCapacitance(CS(off)CD(off)): 3pF, 12.2pF
  • Current-Leakage(IS(off))(Max): 1nA
  • Crosstalk: -96dB @ 1MHz
  • OperatingTemperature: -40°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 28-SOIC (0.295, 7.50mm Width)
  • MUX506IDWR TI, IC SWITCH SINGLE 28SOIC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MUX506IDWR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
