MPC506APG4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 28-DIP (0.600, 15.24mm)
- Description: IC MULTIPLEXER 1X16 28DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MPC506APG4 Specifications:
- MfrPart.: MPC506APG4
- Mfr: Texas Instruments
- Description: IC MULTIPLEXER 1X16 28DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: -
- Multiplexer/DemultiplexerCircuit: 16:1
- NumberofCircuits: 1
- On-StateResistance(Max): 1.5kOhm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): ±5V ~ 22V
- SwitchTime(TonToff)(Max): 200ns, 250ns (Typ)
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 5pF, 50pF
- Current-Leakage(IS(off))(Max): 500pA (Typ)
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Through Hole
- Package/Case: 28-DIP (0.600, 15.24mm)
- MPC506APG4 TI, IC MULTIPLEXER 1X16 28DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MPC506APG4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
