LP3996SD-1525 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: 10-WFDFN Exposed Pad
- Description: IC REG LINEAR 1.5V/2.5V 10WSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LP3996SD-1525 Specifications:
- MfrPart.: LP3996SD-1525
- Mfr: Texas Instruments
- Description: IC REG LINEAR 1.5V/2.5V 10WSON
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- OutputConfiguration: Positive
- OutputType: Fixed
- NumberofRegulators: 2
- Voltage-Input(Max): 6V
- Voltage-Output(Min/Fixed): 1.5V, 2.5V
- Voltage-Output(Max): -
- VoltageDropout(Max): 0.22V @ 150mA, 0.55V @ 150mA
- Current-Output: 150mA, 300mA
- Current-Quiescent(Iq): 100 µA
- Current-Supply(Max): 170 µA
- PSRR: 58dB ~ 45dB, 70dB ~ 60dB (1kHz ~ 20kHz)
- ControlFeatures: Enable
- ProtectionFeatures: Over Temperature, Short Circuit
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 10-WFDFN Exposed Pad
- LP3996SD-1525 TI, IC REG LINEAR 1.5V/2.5V 10WSON, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
LP3996SD-1525, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
