LM5156HQPWPRQ1 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
- Description: 2.2MHZ WIDE VIN AUTOMOTIVE NON-S
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LM5156HQPWPRQ1 Specifications:
- MfrPart.: LM5156HQPWPRQ1
- Mfr: Texas Instruments
- Description: 2.2MHZ WIDE VIN AUTOMOTIVE NON-S
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q100
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- OutputConfiguration: Positive
- Topology: Boost, Flyback, SEPIC
- NumberofOutputs: 1
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 2.97V ~ 60V
- Frequency-Switching: 100kHz ~ 2.2MHz
- DutyCycle(Max): 93%
- SynchronousRectifier: No
- ClockSync: No
- SerialInterfaces: -
- ControlFeatures: Current Limit, Enable, Frequency Control, Power Good, Soft Start
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 14-TSSOP (0.173, 4.40mm Width) Exposed Pad
- LM5156HQPWPRQ1 TI, 2.2MHZ WIDE VIN AUTOMOTIVE NON-S, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
LM5156HQPWPRQ1, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
