LM1086CSX-2.5 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
- Description: IC REG LIN 2.5V 1.5A DDPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LM1086CSX-2.5 Specifications:
- MfrPart.: LM1086CSX-2.5/NOPB
- Mfr: Texas Instruments
- Description: IC REG LIN 2.5V 1.5A DDPAK
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputConfiguration: Positive
- OutputType: Fixed
- NumberofRegulators: 1
- Voltage-Input(Max): 27V
- Voltage-Output(Min/Fixed): 2.5V
- Voltage-Output(Max): -
- VoltageDropout(Max): 1.5V @ 1.5A
- Current-Output: 1.5A
- Current-Quiescent(Iq): 5 mA
- Current-Supply(Max): 10 mA
- PSRR: 72dB (120Hz)
- ControlFeatures: -
- ProtectionFeatures: Over Current, Over Temperature, Short Circuit
- OperatingTemperature: 0°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: TO-263-4, D²Pak (3 Leads + Tab), TO-263AA
- LM1086CSX-2.5 TI, IC REG LIN 2.5V 1.5A DDPAK, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
LM1086CSX-2.5, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
