ISO7760DW Images
- Manufacturer: Texas Instruments (TI)
- Category: Isolators~Digital Isolators Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: DGTL ISO 5000VRMS 6CH GP 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISO7760DW Specifications:
- MfrPart.: ISO7760DW
- Mfr: Texas Instruments
- Description: DGTL ISO 5000VRMS 6CH GP 16SOIC
- Product Category: Isolators~Digital Isolators
- Package: Tube
- Series: -
- PartStatus: Active
- Technology: Capacitive Coupling
- Type: General Purpose
- IsolatedPower: No
- NumberofChannels: 6
- Inputs-Side1/Side2: 6/0
- ChannelType: Unidirectional
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 85kV/µs
- DataRate: 100Mbps
- PropagationDelaytpLH/tpHL(Max): 16ns, 16ns
- PulseWidthDistortion(Max): 4.9ns
- Rise/FallTime(Typ): 1.1ns, 1.4ns
- Voltage-Supply: 2.25V ~ 5.5V
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- ISO7760DW TI, DGTL ISO 5000VRMS 6CH GP 16SOIC, Isolators~Digital Isolators
ISO7760DW, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
