ISO6742DWR Images
- Manufacturer: Texas Instruments (TI)
- Category: Isolators~Digital Isolators Package/Case: 16-SOIC (0.295, 7.50mm Width)
- Description: GENERAL-PURPOSE, QUAD-CHANNEL, 2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ISO6742DWR Specifications:
- MfrPart.: ISO6742DWR
- Mfr: Texas Instruments
- Description: GENERAL-PURPOSE, QUAD-CHANNEL, 2
- Product Category: Isolators~Digital Isolators
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: ISO674x
- PartStatus: Active
- Technology: Capacitive Coupling
- Type: CAN, RS232, RS485, SPI
- IsolatedPower: No
- NumberofChannels: 4
- Inputs-Side1/Side2: 2/2
- ChannelType: Unidirectional
- Voltage-Isolation: 5000Vrms
- CommonModeTransientImmunity(Min): 50kV/µs
- DataRate: 50Mbps
- PropagationDelaytpLH/tpHL(Max): 18ns, 18ns
- PulseWidthDistortion(Max): 7ns
- Rise/FallTime(Typ): 2.6ns, 2.6ns
- Voltage-Supply: 2.25V ~ 5.5V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.295, 7.50mm Width)
- ISO6742DWR TI, GENERAL-PURPOSE, QUAD-CHANNEL, 2, Isolators~Digital Isolators
ISO6742DWR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
