CSD86356Q5D Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerTDFN
- Description: 25V POWERBLOCK N CH MOSFET
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CSD86356Q5D Specifications:
- MfrPart.: CSD86356Q5D
- Mfr: Texas Instruments
- Description: 25V POWERBLOCK N CH MOSFET
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: NexFET™
- PartStatus: Active
- FETType: 2 N-Channel (Half Bridge)
- FETFeature: Logic Level Gate, 5V Drive
- DraintoSourceVoltage(Vdss): 25V
- Current-ContinuousDrain(Id)@25°C: 40A (Ta)
- RdsOn(Max)@IdVgs: 4.5mOhm @ 20A, 5V, 0.8mOhm @ 20A, 5V
- Vgs(th)(Max)@Id: 1.85V @ 250µA, 1.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 7.9nC @ 4.5V, 19.3nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 1.04nF @ 12.5V, 2.51nF @ 12.5V
- Power-Max: 12W (Ta)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerTDFN
- CSD86356Q5D TI, 25V POWERBLOCK N CH MOSFET, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
CSD86356Q5D, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
