CSD86330Q3D Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerLDFN
- Description: MOSFET 2N-CH 25V 20A 8LSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CSD86330Q3D Specifications:
- MfrPart.: CSD86330Q3D
- Mfr: Texas Instruments
- Description: MOSFET 2N-CH 25V 20A 8LSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: NexFET™
- PartStatus: Active
- FETType: 2 N-Channel (Half Bridge)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 25V
- Current-ContinuousDrain(Id)@25°C: 20A
- RdsOn(Max)@IdVgs: 9.6mOhm @ 14A, 8V
- Vgs(th)(Max)@Id: 2.1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 6.2nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 920pF @ 12.5V
- Power-Max: 6W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerLDFN
- CSD86330Q3D TI, MOSFET 2N-CH 25V 20A 8LSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
CSD86330Q3D, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
