CSD85301Q2 Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 6-WDFN Exposed Pad
- Description: MOSFET 2N-CH 20V 5A 6WSON
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CSD85301Q2 Specifications:
- MfrPart.: CSD85301Q2
- Mfr: Texas Instruments
- Description: MOSFET 2N-CH 20V 5A 6WSON
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: NexFET™
- PartStatus: Active
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate, 5V Drive
- DraintoSourceVoltage(Vdss): 20V
- Current-ContinuousDrain(Id)@25°C: 5A
- RdsOn(Max)@IdVgs: 27mOhm @ 5A, 4.5V
- Vgs(th)(Max)@Id: 1.2V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 5.4nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 469pF @ 10V
- Power-Max: 2.3W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 6-WDFN Exposed Pad
- CSD85301Q2 TI, MOSFET 2N-CH 20V 5A 6WSON, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
CSD85301Q2, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
