CSD19533KCS Images
- Manufacturer: Texas Instruments (TI)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220-3
- Description: MOSFET N-CH 100V 100A TO220-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CSD19533KCS Specifications:
- MfrPart.: CSD19533KCS
- Mfr: Texas Instruments
- Description: MOSFET N-CH 100V 100A TO220-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: NexFET™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 100A (Ta)
- DriveVoltage(MaxRdsOnMinRdsOn): 6V, 10V
- RdsOn(Max)@IdVgs: 10.5mOhm @ 55A, 10V
- Vgs(th)(Max)@Id: 3.4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 35 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2670 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 188W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220-3
- CSD19533KCS TI, MOSFET N-CH 100V 100A TO220-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
CSD19533KCS, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
