CD74HCT4316E Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: IC SWITCH QUAD 1X2 16DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CD74HCT4316E Specifications:
- MfrPart.: CD74HCT4316E
- Mfr: Texas Instruments
- Description: IC SWITCH QUAD 1X2 16DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 170Ohm
- Channel-to-ChannelMatching(ΔRon): 5Ohm
- Voltage-SupplySingle(V+): 4.5V ~ 5.5V
- Voltage-SupplyDual(V±): ±1V ~ 5V
- SwitchTime(TonToff)(Max): 37ns, 37ns
- -3dbBandwidth: 200MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 5pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- CD74HCT4316E TI, IC SWITCH QUAD 1X2 16DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
CD74HCT4316E, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
