CD74HC4066E Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 14-DIP (0.300, 7.62mm)
- Description: IC SWITCH QUAD 1X2 14DIP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CD74HC4066E Specifications:
- MfrPart.: CD74HC4066E
- Mfr: Texas Instruments
- Description: IC SWITCH QUAD 1X2 14DIP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 70Ohm
- Channel-to-ChannelMatching(ΔRon): 500mOhm
- Voltage-SupplySingle(V+): 2V ~ 10V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): -
- -3dbBandwidth: 200MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 5pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -72dB @ 1MHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Through Hole
- Package/Case: 14-DIP (0.300, 7.62mm)
- CD74HC4066E TI, IC SWITCH QUAD 1X2 14DIP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
CD74HC4066E, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
