CD4097BNSRG4 Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 24-SOIC (0.209, 5.30mm Width)
- Description: IC MUX/DEMUX DUAL 1X8 24SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CD4097BNSRG4 Specifications:
- MfrPart.: CD4097BNSRG4
- Mfr: Texas Instruments
- Description: IC MUX/DEMUX DUAL 1X8 24SO
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: -
- Multiplexer/DemultiplexerCircuit: 8:1
- NumberofCircuits: 2
- On-StateResistance(Max): 240Ohm
- Channel-to-ChannelMatching(ΔRon): 5Ohm
- Voltage-SupplySingle(V+): 3V ~ 18V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): -
- -3dbBandwidth: 20MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 0.2pF, 35pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 24-SOIC (0.209, 5.30mm Width)
- CD4097BNSRG4 TI, IC MUX/DEMUX DUAL 1X8 24SO, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
CD4097BNSRG4, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
