CD4086BNSR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters - Multi-Function, Configurable Package/Case: 14-SOIC (0.209, 5.30mm Width)
- Description: IC EXPND AND-ORINV GATE 14SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CD4086BNSR Specifications:
- MfrPart.: CD4086BNSR
- Mfr: Texas Instruments
- Description: IC EXPND AND-ORINV GATE 14SO
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters - Multi-Function, Configurable
- Package: Tape & Reel (TR)
- Series: 4000B
- PartStatus: Obsolete
- LogicType: AND/OR/INVERT Gate
- NumberofCircuits: 1
- NumberofInputs: 8 Input (2, 2, 2, 2)
- SchmittTriggerInput: No
- OutputType: Single-Ended
- Current-OutputHighLow: 6.8mA, 6.8mA
- Voltage-Supply: 3V ~ 18V
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.209, 5.30mm Width)
- CD4086BNSR TI, IC EXPND AND-ORINV GATE 14SO, Integrated Circuits (ICs)~Logic - Gates and Inverters - Multi-Function, Configurable
CD4086BNSR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
