CD4013BNSR Images
- Manufacturer: Texas Instruments (TI)
- Category: Integrated Circuits (ICs)~Logic - Flip Flops SupplierDevicePackage: 14-SO
- Description: IC FF D-TYPE DUAL 1BIT 14SOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
CD4013BNSR Specifications:
- MfrPart.: CD4013BNSR
- Mfr: Texas Instruments
- Description: IC FF D-TYPE DUAL 1BIT 14SOP
- Product Category: Integrated Circuits (ICs)~Logic - Flip Flops
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: 4000B
- PartStatus: Active
- Function: Set(Preset) and Reset
- Type: D-Type
- OutputType: Complimentary
- NumberofElements: 2
- NumberofBitsperElement: 1
- ClockFrequency: 24 MHz
- MaxPropagationDelay@VMaxCL: 90ns @ 15V, 50pF
- TriggerType: Positive Edge
- Current-OutputHighLow: 6.8mA, 6.8mA
- Voltage-Supply: 3V ~ 18V
- Current-Quiescent(Iq): 4 µA
- InputCapacitance: 5 pF
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- SupplierDevicePackage: 14-SO
- CD4013BNSR TI, IC FF D-TYPE DUAL 1BIT 14SOP, Integrated Circuits (ICs)~Logic - Flip Flops
CD4013BNSR, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
