6N135 Images
- Manufacturer: Texas Instruments (TI)
- Category: Isolators~Optoisolators - Transistor, Photovoltaic Output Package/Case: 8-DIP (0.300, 7.62mm)
- Description: LOGIC IC OUTPUT OPTOCOUPLER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
6N135 Specifications:
- MfrPart.: 6N135
- Mfr: Texas Instruments
- Description: LOGIC IC OUTPUT OPTOCOUPLER
- Product Category: Isolators~Optoisolators - Transistor, Photovoltaic Output
- Package: Bulk
- Series: -
- PartStatus: Active
- NumberofChannels: 1
- Voltage-Isolation: 5300Vrms
- CurrentTransferRatio(Min): 7% @ 16mA
- CurrentTransferRatio(Max): -
- TurnOn/TurnOffTime(Typ): 200ns, 200ns
- Rise/FallTime(Typ): -
- InputType: DC
- OutputType: Transistor with Base
- Voltage-Output(Max): 15V
- Current-Output/Channel: 8mA
- Voltage-Forward(Vf)(Typ): 1.33V
- Current-DCForward(If)(Max): 25 mA
- VceSaturation(Max): -
- OperatingTemperature: -55°C ~ 100°C
- MountingType: Through Hole
- Package/Case: 8-DIP (0.300, 7.62mm)
- 6N135 TI, LOGIC IC OUTPUT OPTOCOUPLER, Isolators~Optoisolators - Transistor, Photovoltaic Output
6N135, TI authentic parts in stock from TI authorized distributors, order today, can ship immediately.
